GAFFAIR
The versatility of Airstar’s Gaffair makes it a powerful alternative to traditional softbox fixtures. Its soft diffusion is available in a range of sizes and sources that provide a variety of options for hand-held, ground-supported, or suspended / rigged applications.
TECHNICAL DATA
BI-COLOR LED
Available Options
CLOSED STATE
900 W LED
| Unit | 900 W LED - Ellipse |
| Light Source | BI-COLOR LED (2700 K - 6500 K) |
| Power/Plugs | 20 A Edison 110 V |
| Diameter | ø 5.25 ft x 3.23 ft |
| Max Height | N/A |
| Fill | Air-inflated |
| Techs | 1 |
| Set Up Time | 15 min |
| Cable Length | 55 ft |
| Max Wind | 35 mph |
Accessories
- Skirts
- Reflector
- Grid
TUNGSTEN
Available Options
CLOSED STATE
2.5 kW Tungsten
| Unit | 2.5 kW Tungsten - Ellipse |
| Lamps/Socket | 1x 2.5 kW / G38 |
| Power/Plugs | 100 A Bates 220 V |
| Diameter | 6.55 ft |
| Max Height | N/A |
| Fill | Air-inflated |
| Techs | 1 |
| Set Up Time | 15 min |
| Cable Length | 50 ft |
| Max Wind | 35 mph |
Accessories
- Skirts
- Reflector
- Grid
HMI
Available Options
CLOSED STATE
400 W HMI
| Unit | 400 W HMI - Ellipse |
| Lamps/Socket | 1x 400 W / G22 |
| Power/Plugs | 20 A Edison 110 V |
| Diameter | 2.5 ft |
| Max Height | N/A |
| Fill | Air-inflated |
| Techs | 1 |
| Set Up Time | 15 min |
| Cable Length | 50 ft |
| Max Wind | 35 mph |
1.2 kW HMI
| Unit | 1.2 kW HMI - Ellipse |
| Lamps/Socket | 1 x 1.2 kW / G38 |
| Power/Plugs | 20 A Edison 110 V |
| Diameter | 6.55 ft |
| Max Height | N/A |
| Fill | Air-inflated |
| Techs | 1 |
| Set Up Time | 15 min |
| Cable Length | 50 ft |
| Max Wind | 35 mph |
2.5 kW HMI
| Unit | 2.5 kW HMI - Ellipse |
| Lamps/Socket | 1 x 2.5 kW / G38 |
| Power/Plugs | 60 A Edison 110 V |
| Diameter | 7.2 ft |
| Max Height | N/A |
| Fill | Air-inflated |
| Techs | 1 |
| Set Up Time | 20 min |
| Cable Length | 50 ft |
| Max Wind | 35 mph |
4 kW HMI
| Unit | 4 kW HMI - Ellipse |
| Lamps/Socket | 1 x 4 kW / G38 |
| Power/Plugs | 60 A Edison 110 V |
| Diameter | 7.2 ft |
| Max Height | N/A |
| Fill | Air-inflated |
| Techs | 1 |
| Set Up Time | 20 min |
| Cable Length | 50 ft |
| Max Wind | 35 mph |
Accessories
- Skirts
- Reflector
- Grid
Sodium/Mercury
Available Options
CLOSED STATE
1 kW Sodium/Mercury
| Unit | 1 kW Sodium/Mercury - Ellipse |
| Lamps/Socket | 1x 1 kW / Mogul E39 |
| Power/Plugs | 20 A Edison 110 V |
| Diameter | 6.55 ft |
| Max Height | N/A |
| Fill | Air-inflated |
| Techs | 1 |
| Set Up Time | 15 min |
| Cable Length | 50 ft |
| Max Wind | 35 mph |
Accessories
- Skirts
- Reflector
- Grid
