Ellipse – Sphere
Airstar’s Elliptical and Spherical film lighting are our original light balloons. These units are versatile, offering focused lighting with a wide variety of positioning options. They are perfect for any indoor or outdoor application that needs powerful output and performance.
TECHNICAL DATA
LED
Available Options
CLOSED STATE
1.8 kW LED
| Unit | 20 kW Hybrid - Ellipse |
| Light Source | BI-COLOR LED (2700 K - 6500 K) |
| Power / Plugs | 20 A Edison 110 V |
| Diameter | 11.3 ft x 8.8 ft |
| Max Height | 80 ft |
| Helium Tanks | 3 (291 cft) |
| Techs | 1 |
| Set Up Time | 1 hr |
| Cable Length | 70 ft |
| Max Wind | 15 mph |
Accessories
- Skirts
- Reflectors
TUNGSTEN
Available Options
CLOSED STATE
4 kW Tungsten (6 ft x 8 ft)
| Unit | 4 kW Tungsten |
| Lamp Socket | 4x 1 kW / G6.35 |
| Power / Plugs | 100 A Bates 220 V |
| Diameter | 6.5 ft | 6 ft x 8 ft |
| Max Height | 40 ft |
| Helium Tanks | 1 (291 cft) |
| Techs | 1 |
| Set Up Time | 30 min |
| Cable Length | 45 ft |
| Max Wind | 10 mph |
4 kW Tungsten (8 ft x 10 ft)
| Unit | 4 kW Tungsten |
| Lamp Socket | 4x 1 kW / G6.35 |
| Power / Plugs | 100 A Bates 220 V |
| Diameter | 8 ft | 8 ft x 10 ft |
| Max Height | 45 ft |
| Helium Tanks | 2 (291 cft) |
| Techs | 1 |
| Set Up Time | 30 min |
| Cable Length | 45 ft |
| Max Wind | 15 mph |
5 kW Tungsten (8 ft x 10 ft)
| Unit | 5 kW Tungsten |
| Lamp Socket | 2x 2.5 kW / G38 |
| Power / Plugs | 100 A Bates 220 V |
| Diameter | 8 ft | 8 ft x 10 ft |
| Max Height | 40 ft |
| Helium Tanks | 2 (291 cft) |
| Techs | 1 |
| Set Up Time | 30 min |
| Cable Length | 45 ft |
| Max Wind | 15 mph |
5 kW Tungsten (10 ft x 12 ft)
| Unit | 5 kW Tungsten |
| Lamp Socket | 2x 2.5 kW / G38 |
| Power / Plugs | 100 A Bates 220 V |
| Diameter | 10 ft | 10 ft x 12 ft |
| Max Height | 45 ft |
| Helium Tanks | 3 (291 cft) |
| Techs | 1 |
| Set Up Time | 30 min |
| Cable Length | 45 ft |
| Max Wind | 15 mph |
8 kW Tungsten
| Unit | 8 kW Tungsten |
| Lamp Socket | 8x 1 kW / G6.35 |
| Power / Plugs | 100 A Bates 220 V |
| Diameter | 12 ft | 12 ft x 16 ft |
| Max Height | 70 ft |
| Helium Tanks | 5 (291 cft) |
| Techs | 1 |
| Set Up Time | 50 min |
| Cable Length | 100 ft |
| Max Wind | 20 mph |
10 kW Tungsten
| Unit | 10 kW Tungsten |
| Lamp Socket | 2x 5 kW / G38 |
| Power / Plugs | 100 A Bates 220 V |
| Diameter | 12 ft | 12 ft x 16 ft |
| Max Height | 70 ft |
| Helium Tanks | 5 (291 cft) |
| Techs | 1 |
| Set Up Time | 50 min |
| Cable Length | 100 ft |
| Max Wind | 20 mph |
15 kW Tungsten
| Unit | 15 kW Tungsten |
| Lamp Socket | 2x 5 kW + 2x 2.5 kW / G38 |
| Power / Plugs | 100 A Bates 220 V SP |
| Diameter | 16 ft 5 inch |
| Max Height | 80 ft |
| Helium Tanks | 10 (291 cft) |
| Techs | 2 |
| Set Up Time | 70 min |
| Cable Length | 120 ft |
| Max Wind | 25 mph |
20 kW Tungsten
| Unit | 20 kW Tungsten |
| Lamp Socket | 4x 5 kW / G38 |
| Power / Plugs | 100 A Bates 220 V SP |
| Diameter | 16 ft 5 inch |
| Max Height | 80 ft |
| Helium Tanks | 10 (291 cft) |
| Techs | 2 |
| Set Up Time | 70 min |
| Cable Length | 120 ft |
| Max Wind | 25 mph |
Accessories
- Skirts
- Reflectors
HMI
Available Options
CLOSED STATE
1.15 kW HMI
| Unit | 1,150 W HMI |
| Lamp Socket | 2x 575 W / G22 |
| Power / Plugs | 2x 20 A Edison 110 V |
| Diameter | 6.5 ft | 6.5 ft x 8ft |
| Max Height | 35 ft |
| Helium Tanks | 1 (291 cft) |
| Techs | 1 |
| Set Up Time | 30 min |
| Cable Length | 45 ft |
| Max Wind | 10 mph |
2.4 kW HMI (8 ft x 10 ft)
| Unit | 2.4 kW HMI |
| Lamp Socket | 2x 1.2 kW / G38 |
| Power / Plugs | 2x 20 A Edison 110 V |
| Diameter | 8 ft | 8 ft x 10 ft |
| Max Height | 35 ft |
| Helium Tanks | 2 (291 cft) |
| Techs | 1 |
| Set Up Time | 35 min |
| Cable Length | 55 ft |
| Max Wind | 15 mph |
2.4 kW HMI (10 ft x 12 ft)
| Unit | 2.4 kW HMI |
| Lamp Socket | 2x 1.2 kW / G38 |
| Power / Plugs | 2x 20 A Edison 110 V |
| Diameter | 10 ft | 10 ft x 12 ft |
| Max Height | 45 ft |
| Helium Tanks | 3 (291 cft) |
| Techs | 1 |
| Set Up Time | 35 min |
| Cable Length | 55 ft |
| Max Wind | 15 mph |
4.8 kW HMI
| Unit | 4.8 kW HMI |
| Lamp Socket | 4x 1.2 kW / G38 |
| Power / Plugs | 4x 20 A Edison 110 V |
| Diameter | 12 ft | 12 ft x 14 ft |
| Max Height | 65 ft |
| Helium Tanks | 5 (291 cft) |
| Techs | 1 |
| Set Up Time | 45 min |
| Cable Length | 100 ft |
| Max Wind | 20 mph |
5 kW HMI
| Unit | 5 kW HMI - Ellipse |
| Lamp Socket | 2x 2.5 kW / G38 |
| Power / Plugs | 2x 60 A Bates 110 V |
| Diameter | 14 ft x 16 ft |
| Max Height | 75 ft |
| Helium Tanks | 8 (291 cft) |
| Techs | 2 |
| Set Up Time | 60 min |
| Cable Length | 100 ft |
| Max Wind | 25 mph |
8 kW HMI
| Unit | 8 kW HMI - Ellipse |
| Lamp Socket | 2x 4 kW / G38 |
| Power / Plugs | 2x 60 A Bates 110 V |
| Diameter | 14 ft x 16 ft |
| Max Height | 75 ft |
| Helium Tanks | 8 (291 cft) |
| Techs | 2 |
| Set Up Time | 60 min |
| Cable Length | 100 ft |
| Max Wind | 25 mph |
10 kW HMI
| Unit | 10 kW HMI - Sphere |
| Lamp Socket | 4x 2.5 kW / G38 |
| Power / Plugs | 4x 60 A Bates 110 V |
| Diameter | 16 ft 5 inch |
| Max Height | 80 ft |
| Helium Tanks | 10 (291 cft) |
| Techs | 2 |
| Set Up Time | 75 min |
| Cable Length | 100 ft |
| Max Wind | 25 mph |
16 kW HMI
| Unit | 16 kW HMI - Sphere |
| Lamp Socket | 4x 4 kW / G38 |
| Power / Plugs | 4x 60 A Bates 110 V |
| Diameter | 16 ft 5 inch |
| Max Height | 80 ft |
| Helium Tanks | 10 (291 cft) |
| Techs | 2 |
| Set Up Time | 75 min |
| Cable Length | 100 ft |
| Max Wind | 25 mph |
Accessories
- Skirts
- Reflectors
Hybrid
Available Options
CLOSED STATE
2.575 kW Hybrid (Tungsten + HMI)
| Unit | 2,575 W Hybrid |
| Lamp Socket | 2x 1 kW + 1x 575 W / G6.35 + G22 |
| Power / Plugs | 100 A 220 V + 20 A Edison 110 V |
| Diameter | 6.5 ft | 6.5 ft x 8 ft |
| Max Height | 40 ft |
| Helium Tanks | 1 (291 cft) |
| Techs | 1 |
| Set Up Time | 30 min |
| Cable Length | 45 ft |
| Max Wind | 10 mph |
3.7 kW Hybrid (TUNG + HMI) | (8 ft x 10 ft)
| Unit | 3.7 kW Hybrid |
| Lamp Socket | 1x 2.5 kW + 1x 1.2 kW / G38 |
| Power / Plugs | 100 A 220 V + 20 A Edison 110 V |
| Diameter | 8 ft | 8 ft x 10 ft |
| Max Height | 35 ft |
| Helium Tanks | 2 (291 cft) |
| Techs | 1 |
| Set Up Time | 40 min |
| Cable Length | 45 ft |
| Max Wind | 15 mph |
3.7 kW Hybrid (TUNG + HMI) | (10 ft x 12 ft)
| Unit | 3.7 kW Hybrid |
| Lamp Socket | 1x 2.5 kW + 1x 1.2 kW / G38 |
| Power / Plugs | 100 A 220 V + 20 A Edison 110 V |
| Diameter | 10 ft | 10 ft x 12 ft |
| Max Height | 45 ft |
| Helium Tanks | 3 (291 cft) |
| Techs | 1 |
| Set Up Time | 40 min |
| Cable Length | 45 ft |
| Max Wind | 15 mph |
7.4 kW Hybrid (Tungsten + HMI)
| Unit | 7.4 kW Hybrid |
| Lamp Socket | 2x 2.5 kW + 2x 1.2 kW / G38 |
| Power / Plugs | 100 A 220 V + 2x 20 A Edison 110 V |
| Diameter | 12 ft | 12 ft x 14 ft |
| Max Height | 60 ft |
| Helium Tanks | 5 (291 cft) |
| Techs | 1 |
| Set Up Time | 55 min |
| Cable Length | 100 ft |
| Max Wind | 20 mph |
8.4 kW Hybrid (Tungsten + HMI)
| Unit | 8.4 kW Hybrid - Ellipse |
| Lamp Socket | 6x 1 kW + 2x 1.2 kW / G6.35 + G38 |
| Power / Plugs | 100 A 220 V + 2x 20 A Edison 110 V |
| Diameter | 8.8 ft x 12 ft |
| Max Height | 40 ft |
| Helium Tanks | 4 (291 cft) |
| Techs | 1 |
| Set Up Time | 40 min |
| Cable Length | 55 ft |
| Max Wind | 15 mph |
9.6 kW Hybrid (Tungsten + HMI)
| Unit | 9.6 kW Hybrid - Ellipse |
| Lamp Socket | 6x 1 kW + 3x 1.2 kW / G6.35 + G38 |
| Power / Plugs | 100 A 220 V + 3x 20 A Edison 110 V |
| Diameter | 12 ft x 14 ft |
| Max Height | 50 ft |
| Helium Tanks | 5 (291 cft) |
| Techs | 1 |
| Set Up Time | 55 min |
| Cable Length | 100 ft |
| Max Wind | 20 mph |
18 kW Hybrid (TUNG + HMI) | (14 ft x 20.6 ft)
| Unit | 18 kW Hybrid - Ellipse |
| Lamp Socket | 6x 1 kW + 3x 4 kW / G6.35 + G38 |
| Power / Plugs | 100 A 220 V + 3x 60 A Bates 110 V |
| Diameter | 14 ft x 20.6 ft |
| Max Height | 80 ft |
| Helium Tanks | 12 (291 cft) |
| Techs | 2 |
| Set Up Time | 75 min |
| Cable Length | 100 ft |
| Max Wind | 20 mph |
18 kW Hybrid (TUNG + HMI) | (16.5 ft)
| Unit | 18 kW Hybrid - Sphere |
| Lamp Socket | 2x 5 kW + 2x 4 kW / G38 |
| Power / Plugs | 100 A 220 V SP + 2x 60 A Bates 110 V |
| Diameter | 16.5 ft |
| Max Height | 80 ft |
| Helium Tanks | 10 (291 cft) |
| Techs | 2 |
| Set Up Time | 75 min |
| Cable Length | 100 ft |
| Max Wind | 20 mph |
19 kW Hybrid (Tungsten + HMI)
| Unit | 19 kW Hybrid - Ellipse |
| Lamp Socket | 6x 1 kW + 1x 5 kW + 2x 4 kW / G6.35 + G38 |
| Power / Plugs | 100 A 220 V + 2x 60 A Bates 110 V |
| Diameter | 14 ft x 20.6 ft |
| Max Height | 80 ft |
| Helium Tanks | 12 (291 cft) |
| Techs | 2 |
| Set Up Time | 75 min |
| Cable Length | 100 ft |
| Max Wind | 20 mph |
20 kW Hybrid (Tungsten + HMI)
| Unit | 20 kW Hybrid - Ellipse |
| Lamp Socket | 8x 1 kW + 3x 4 kW / G6.35 + G38 |
| Power / Plugs | 100 A 220 V + 3x 60 A Bates 110 V |
| Diameter | 14 ft x 20.6 ft |
| Max Height | 80 ft |
| Helium Tanks | 12 (291 cft) |
| Techs | 2 |
| Set Up Time | 75 min |
| Cable Length | 100 ft |
| Max Wind | 20 mph |
Accessories
- Skirts
- Reflectors
Sodium – Mercury
Available Options
CLOSED STATE
4 kW Sodium/Mercury
| Unit | 4 kW Sodium/Mercury - Sphere |
| Lamp Socket | 4x 1 kW / Mogul E39 |
| Power / Plugs | 4x 20 A Edison 110 V |
| Diameter | 14 ft |
| Max Height | 60 ft |
| Helium Tanks | 5 (291 cft) |
| Techs | 1 |
| Set Up Time | 65 min |
| Cable Length | 100 ft |
| Max Wind | 15 mph |
Accessories
- Skirts
- Reflectors
