Diamond
The multifaceted design of Airstar’s Diamond film lighting maximizes overall light projection. Configuration of each individual panel also allows for a more precise control of the directional throw of light.
TECHNICAL DATA
TUNGSTEN
Available Options
CLOSED STATE
4 kW Tungsten
| Unit | 4 kW Tungsten |
| Lamp Socket | 4x 1 kW / G6.35 |
| Power / Plugs | 100 A Bates 220 V |
| Diameter | 7.2 ft x 7.2 ft |
| Max Height | 30 ft |
| Helium Tanks | 1 (291 cft) |
| Techs | 1 |
| Set Up Time | 30 min |
| Cable Length | 45 ft |
| Max Wind | 10 mph |
8 kW Tungsten
| Unit | 8 kW Tungsten |
| Lamp Socket | 8x 1 kW / G6.35 |
| Power / Plugs | 100 A Bates 220 V |
| Diameter | 12.5 ft x 12.5 ft |
| Max Height | 75 ft |
| Helium Tanks | 6 (291 cft) |
| Techs | 2 |
| Set Up Time | 50 min |
| Cable Length | 100 ft |
| Max Wind | 20 mph |
10 kW Tungsten
| Unit | 10 kW Tungsten |
| Lamp Socket | 2x 5 kW or 4x 25 kW / G38 |
| Power / Plugs | 100 A Bates 220 V |
| Diameter | 12.5 ft x 12.5 ft |
| Max Height | 75 ft |
| Helium Tanks | 6 (291 cft) |
| Techs | 2 |
| Set Up Time | 50 min |
| Cable Length | 100 ft |
| Max Wind | 20 mph |
Accessories
- Skirts
- Reflectors
- Bobbinet
HMI
Available Options
CLOSED STATE
1.15 kW HMI
| Unit | 1,150 W HMI |
| Lamp Socket | 2x 575 W / G22 |
| Power / Plugs | 2x 20 A Edison 110 V |
| Diameter | 7.2 ft x 7.2 ft |
| Max Height | 30 ft |
| Helium Tanks | 1 (291 cft) |
| Techs | 1 |
| Set Up Time | 30 min |
| Cable Length | 45 ft |
| Max Wind | 10 mph |
4.8 kW HMI
| Unit | 4.8 kW HMI |
| Lamp Socket | 4x 1.2 kW / G38 |
| Power / Plugs | 4x 20 A Edison 110 V |
| Diameter | 12.5 ft x 12.5 ft |
| Max Height | 65 ft |
| Helium Tanks | 6 (291 cft) |
| Techs | 2 |
| Set Up Time | 50 min |
| Cable Length | 100 ft |
| Max Wind | 15 mph |
5 kW HMI
| Unit | 5 kW HMI |
| Lamp Socket | 2x 2.5 kW / G38 |
| Power / Plugs | 2x 60 A Edison 110 V |
| Diameter | 12.5 ft x 12.5 ft |
| Max Height | 65 ft |
| Helium Tanks | 6 (291 cft) |
| Techs | 2 |
| Set Up Time | 50 min |
| Cable Length | 100 ft |
| Max Wind | 15 mph |
8 kW HMI
| Unit | 8 kW HMI |
| Lamp Socket | 2x 4 kW / G38 |
| Power / Plugs | 4x 60 A Edison 110 V |
| Diameter | 12.5 ft x 12.5 ft |
| Max Height | 60 ft |
| Helium Tanks | 6 (291 cft) |
| Techs | 2 |
| Set Up Time | 50 min |
| Cable Length | 100 ft |
| Max Wind | 15 mph |
Accessories
- Skirts
- Reflectors
- Bobbinet
Hybrid
Available Options
CLOSED STATE
1.875 kW Hybrid (Tungsten + HMI)
| Unit | 1,875 W Hybrid |
| Lamp Socket | 2x 650 W + 1x 575 W / G6.35 + G22 |
| Power / Plugs | 100 A Bates 220 V + 20 A Edison 110 V |
| Diameter | 7.2 ft x 7.2 ft |
| Max Height | 30 ft |
| Helium Tanks | 1 (291 cft) |
| Techs | 1 |
| Set Up Time | 30 min |
| Cable Length | 45 ft |
| Max Wind | 10 mph |
2.575 kW Hybrid (Tungsten + HMI)
| Unit | 2,575 W Hybrid |
| Lamp Socket | 2x 1 kW + 1x 575 W / G6.35 + G22 |
| Power / Plugs | 100 A Bates 220 V + 60 A Edison 110 V |
| Diameter | 7.2 ft x 7.2 ft |
| Max Height | 30 ft |
| Helium Tanks | 1 (291 cft) |
| Techs | 1 |
| Set Up Time | 30 min |
| Cable Length | 45 ft |
| Max Wind | 10 mph |
5 kW Hybrid (Tungsten + HMI)
| Unit | 5 kW Hybrid |
| Lamp Socket | 1x 2.5 kW + 1x 2.5 kW / G38 |
| Power / Plugs | 100 A Bates 220 V + 60 A Bates 110 V |
| Diameter | 12.5 ft x 12.5 ft |
| Max Height | 60 ft |
| Helium Tanks | 6 (291 cft) |
| Techs | 2 |
| Set Up Time | 55 min |
| Cable Length | 100 ft |
| Max Wind | 15 mph |
7.4 kW Hybrid (Tungsten + HMI)
| Unit | 7.4 kW Hybrid |
| Lamp Socket | 2x 2.5 kW + 2x 1.2 kW / G38 |
| Power / Plugs | 100 A Bates 220 V + 2x 20 A Edison 110 V |
| Diameter | 12.5 ft x 12.5 ft |
| Max Height | 60 ft |
| Helium Tanks | 6 (291 cft) |
| Techs | 2 |
| Set Up Time | 55 min |
| Cable Length | 100 ft |
| Max Wind | 15 mph |
7.5 kW Hybrid (Tungsten + HMI)
| Unit | 7.5 kW Hybrid |
| Lamp Socket | 1x 5 kW + 1x 2.5 kW / G38 |
| Power / Plugs | 100 A Bates 220 V + 20 A Edison 110 V |
| Diameter | 12.5 ft x 12.5 ft |
| Max Height | 60 ft |
| Helium Tanks | 6 (291 cft) |
| Techs | 2 |
| Set Up Time | 55 min |
| Cable Length | 100 ft |
| Max Wind | 15 mph |
9 kW Hybrid (Tungsten + HMI)
| Unit | 9 kW Hybrid |
| Lamp Socket | 1x 5 kW + 1x 4 kW / G38 |
| Power / Plugs | 100 A Bates 220 V + 60 A Bates 110 V |
| Diameter | 12.5 ft x 12.5 ft |
| Max Height | 60 ft |
| Helium Tanks | 6 (291 cft) |
| Techs | 2 |
| Set Up Time | 55 min |
| Cable Length | 100 ft |
| Max Wind | 15 mph |
Accessories
- Skirts
- Reflectors
- Bobbinet
Sodium – Mercury
Available Options
CLOSED STATE
4 kW Sodium/Mercury
| Unit | 4 kW Sodium/Mercury |
| Lamp Socket | 4x 1 kW / Mogul E39 |
| Power / Plugs | 4x 20 A Edison 110 V |
| Diameter | 12.5 ft x 12.5 ft |
| Max Height | 60 ft |
| Helium Tanks | 6 (291 cft) |
| Techs | 2 |
| Set Up Time | 65 min |
| Cable Length | 100 ft |
| Max Wind | 15 mph |
Accessories
- Skirts
- Reflectors
- Bobbinet
